Dry Scroll Vacuum Pumps

ANEST IWATA (Japan)

ANEST IWATA in the North America subsidiary of ANEST IWATA Corporation in Japan, which is a leading manufacturer specializing in painting equipment, turnkey coating systems, air compressors and high-end dry vacuum pumps.

As part of the world-class operation we have two market specific divisions within our North American headquarters that strive to exceed the highly advanced needs of North American industries with innovative, state-of-the-art technologies and services.

ANEST IWATA Air Engineering:

Anest Iwata Air Engineering, Inc. is a manufacturer of air compressors, vacuum pumps and related products. We provide oil free air compressors into a variety of industries such as pharmaceutical, food & beverage, Research & Development and industrial. We were the first in the world to develop an air cooled dry scroll vacuum pump utilized in various high end industries such as semiconductor/electronics, universities and research institutes.

OIL-FREE SCROLL VACUUM PUMPS

Excellent in continuous operation between atmosphere
and vacuum and in the displacement of water vapor.

ISP SCROLL INFORMATION

ANEST IWATA was the first in the world to develop the air-cooled, oil-free, scroll-type vacuum pumps. Our oil-free scroll vacuum pumps are compact and less noise/vibration emitting than other dry vacuum pumps. They are highly valued by customers who need clean, high quality vacuum, especially in analytical and semiconductor related fields.

ISP series of vacuum pumps offer a clean vacuum environment and eliminate the nuisance of cumbersome lubricant maintenance or sealing water administration. ISP is free from installation restrictions because of its air-cooled system. ISP maintains low power consumption from atmosphere to maximum pressure. Maximum pressure is 1[Pa] High reliability.

ISP APPLICATION

Sputtering equipment, Vacuum deposition equipment, Ion plating equipment
Accelerator, Synchrotron Radiation
Surface modification, Electron beam process
Gas recovery devices
Vacuum equipment
Leak detectors
Device handling system
Vacuum furnace, Heat treatment furnace
Laboratory use
Vacuum packaging machine
Precaution for dry scroll vacuum pump

Evacuation Gases
This pumping system is suitable for clean processes only. Do not use explosive, flammable, toxic or corrosive substances or substances which contain chemicals, solvents or particles. ANEST IWATA will not perform maintenance work on pumps which have used hazardous substances.

Ambient Temperature
Use at ambient operation temperature in the range of 5°C to 40°C.

DVSL DRY SCROLL VACUUM PUMP

Precaution for dry scroll vacuum pump

Evacuation gases
This pumping system is suitable for clean processes only. Do not use explosive, flammable, toxic or corrosive substances or substances which contain chemicals, solvents or particles. ANEST IWATA will not perform maintenance work on pumps which have used hazardous substances.

Ambient Temperature
Use at ambient operation temperature in the range of 5°C to 40°C.

Air flushing

Purpose of air flushing

Pumping humid gas through the vacuum pump can cause condensed moisture to remain in the pump.
This remaining moisture can cause the final pressure or pump to fail.
The air flushing process is necessary to pump the remaining moisture out of the pump.
The air flushing process not only pumps the remaining moisture out of the pump, but also restores the final pressure.
